Input:

• Any standard signal as ordered (0...10V, 0/4...20mA etc.).
• Auxiliary power supply voltage for a two-wire transmitter.

Outputs:

• Any standard signal as ordered (0...10V, 0/4...20mA etc.).
• Option to control a 4...20mA current loop supplied from the outside (passive output).

Power supply:

• 24V_DC.

Additional information:

• Input, output and power supply circuits galvanically separated from each other.
• 2 outputs in one rail housing.
• More information in: DATASHEET (download).
