S2Ex[ic]-ZW2p

Repeater-supplier-separator of signal 4...20mA for two-wire transmitters, output active or passive, 2 outputs, with intrinsically safe barrier Ex Atex

245.00 €

Description

Intrinsically safe input:

  • Current 4...20mA.
  • Auxiliary power supply voltage for a two-wire transmitter.

Non-intrinsically safe outputs:

  • Current IOUT=IIN.
  • Active or passive.

Power supply:

  • 24VDC.

Additional information:

  • Explosion-proof construction designation:
    • II (3) G [Ex ic Gc] IIC;
    • II (3) D [Ex ic Dc] IIIC;
    • II 3G Ex ec II T4 Gc.
  • Input, output and power supply circuits galvanically separated from each other.
  • 2 outputs in one rail housing.
  • More information in: DATASHEET (download).
