Non-intrinsically safe input:

• Current 4...20mA.

Intrinsically safe output:

• Current I_OUT=I_IN.

Power supply:

• Separator supplied from the input.

Additional information:

• Bidirectional HART protocol transmission (max 20kHz).
• Explosion-proof construction designation:

  • I (M1) [Ex ia Ma] I;
  • II (1) G [Ex ia Ga] IIC;
  • II (1) D [Ex ia Da] IIIC.
• Input and output circuits galvanically separated from each other.
• 1 channel in rail housing.
• More information in: DATASHEET (download).
