Input:

• Signal range:
  • - NAMUR sensors,
  • - other three-wire sensors,
  • - potential-free contacts,
  • - PNP, NPN (OC),
  • - voltage 1mV...100V,
  • - current 0,01mA...5A.
• Frequency band 1Hz...10kHz.
• Auxiliary power supply voltage for input sensors 0...6V_DC.

Output:

• Control of a 4...20mA current loop.

Power supply:

• Converter supplied from the output.

Additional information:

• Input and output circuits galvanically separated from each other.
• 1 channel in rail housing.
• More information in: DATASHEET (download).
