Input:

• RS485 MODBUS RTU, 50...115200 bd.
• Up to 254 devices in one network.

Outputs:

• Two independent standard analog outputs (from range 0...21mA, 0...11V) set by the user during configuration.

Power supply:

• 24V_DC.

Additional information:

• Input, output and power supply circuits galvanically separated from each other.
• 2 outputs in one rail housing.
• More information in: DATASHEET (download).
